2019 Dremel 3D20 3D Printer – Review the Specs

Picture of Florian Gehrke
by Florian Gehrke
Apr 16, 2019

2019 Dremel 3D20 3D Printer – Review the Specs

The Dremel DigiLab 3D20 is an desktop 3D printer aimed at schools and universities. Read why it's interesting for makers, educators, and beginners alike.

Most people may know Dremel as a company that produces handy tools for homeowners and hobbyists.

Ever since Dremel set up their DigiLab Division and entered the 3D printing universe with their 3D printers, they have become a successful, education-focused player in the industry. Following the same path, the Dremel DigiLab 3D20 3D printer is made with beginners, casual users, and especially schools and universities in mind. Dremel mission statement is to provide learning opportunities by making easy-to-use printers.

Join us as we review the specs of the Dremel 3D20.

Dremel Digilab 3D20

Product image of Dremel Digilab 3D20

Dremel 3D20 – Review the Specs Features

Let’s see what the Dremel 3D20 brings to the table.

1. Ready for Printing Right Out of the Box

In theory, you just take the Dremel 3D20 out of the box and get ready for printing in under half an hour. The machine comes pre-assembled, all you have to do is to feed the filament and level the printing bed. Unfortunately, the Dremel 3D20 isn’t auto-calibrating, so you have to undergo the well-known procedure of bed leveling, which is also explained in depth in the detailed step-by-step instruction. Even complete novices should be able to master this in the first attempt.

2. Fully Enclosed Desktop Printer

Another feature which goes hand in hand with making this printer suitable for school environments – apart from its actual size – is the fully enclosed design of the Dremel3D20. It retains an even temperature and adds an extra safety precaution. Plus it helps to muffle the operating sound a bit.  However, the Dremel 3D20 is not equipped with any kind of filtration system. Although PLA is mostly fine, you should keep that in mind when exposing yourself or others to the fumes.

3. A Curriculum for Teachers

There’s one thing that makes the Dremel 3D20 stand out from the many printers in the price category around $500 is its curriculum. If you are an educator wanting to share the many facets of 3D printing, this will definitely help. You can take a look at the lesson plans right here.

And if you want to know more about the best 3D printers for schools, please continue here.

4. PLA Only

First and foremost, the Dremel 3D20 only allows for PLA filament to be used – it does not have a heated bed, as would be necessary for other filament types such as ABS.

There’s nothing wrong with a “just PLA” machine, but be aware that you might be missing out on some materials that can be interesting when you get deeper into 3D printing.

Furthermore, this printer has been designed for spools that are only a quarter the size of a regular spool. On top, the Dremel 3D20 does not – at least officially – allow for any third-party filament to be used. It is supposed to only operate with Dremel PLA, which is slightly more expensive than off-brand material. Although some tinkerers have found ways to use bigger, and more importantly, third-party spools.

Advanced users will feel boxed in with this printer, as it does not allow for any modifications.

Dremel 3D20 – Review the Specs Technical Specification

Image of Dremel 3D20 – Review the Specs: Technical Specification

GENERAL SPECIFICATIONS

  • Technology: FDM
  • Year: 2015
  • Assembly: Fully assembled
  • Mechanical arrangement: Cartesian style
  • Manufacturer: Dremel

3D PRINTING PROPERTIES

  • Build volume: 230 x 150 x 140 mm
  • Layer height: 100 microns
  • Extruder type: Single
  • Nozzle size: 0.4 mm
  • Max. extruder temperature: 230 °C
  • Heated bed: No
  • Print chamber: Enclosed
  • Bed leveling: Manual
  • Operating Interface: Full-color touchscreen
  • Connectivity: USB, SD-Card
  • Build-in camera for monitoring: No

MATERIALS:

  • Filament diameter: 1.75 mm
  • Third party filament: No
  • Filament materials: Dremel PLA only

SOFTWARE REQUIREMENTS:

  • Operating system: Windows (32/64-bit Vista or later), Mac (OS X 10.8 or later), Ubuntu (14.04 or later)
  • Recommended Slicer: Dremel Software, Simplify 3D
  • File types:  STL, OBJ, DAE, AMF

DIMENSIONS AND WEIGHT:

  • Assembled dimensions: 400 x 485 x 355 mm
  • Weight: 8.85 kg

Dremel 3D20 – Review the Specs Where to buy

You can buy the Dremel 3D20 from the following shops.

Dremel Digilab 3D20

Product image of Dremel Digilab 3D20
